General Specifications
Output power (W) 800 W RMS (IEC60268)
Power input 100 – 240 V ~ 50 / 60 Hz
Signal-to-Noise Ratio > 80 dB
Audio Specifications
Frequency response 32 Hz – 20 kHz
Transducer 2 × 9" (243 mm) woofers, 2 × 1.25" (30 mm) dome tweeters
Dimensions
Dimensions (W × H × D) (cm) 41.6 × 94.2 × 40.6
Dimensions (W × H × D) (in) 16.38 × 37.1 × 16.0
Weight (kg) 31
Weight (lbs) 68.3
Control and Connection Specifications
Bluetooth profile A2DP V1.4, AVRCP V1.6
Bluetooth transmitter frequency range (GHz) 2.4 – 2.4835
Bluetooth transmitter modulation GFSK, π/4 DQPSK, 8DPSK
Bluetooth transmitter power ≤ 18 dBm (EIRP)
Bluetooth version 5.4
USB-C charge out PDO (5V/3A, 9V/3A, 15V/2A, 20V/1.5A); PPS (5–11V/2.7A, 5–16V/1.85A)
Aux-in 250 mV RMS (3.5 mm connector)
Mic-in 20 mV RMS
Guitar-in 100 mV RMS
Line-in 100 mV RMS
Bluetooth input (dBFS) -12
USB format FAT16, FAT32
Supported music file formats .MP3, .WAV, .FLAC
Battery
Battery charge time (hrs) 3
Battery type 2 × JBL BATTERY 600, Li-ion 99.02 Wh
Cable length (ft) 6.6
Cable length (m) 2
Cable type AC power cable (type varies by region)
Maximum music playing time (hrs) 15
Features
Bluetooth Yes
Lightshow Yes
Supports Auracast Yes
Waterproof Yes
XLR inputs Yes
JBL Original Pro Sound Yes
IP Code IPX4
JBL PartyBox App True
Dual Mic & Guitar inputs Yes
