- os: google tv
- screen size: 813 mm
- ips / va display
- resolution: 1366 x 768 (hd ready)
- ram: 1.5 gb , rom: 8 gb
- aqua seal
- dolby audio sound
cpu
arm cortex-a55 quad core, 1.5ghz
gpu
mali-g31 mp2
ddr ram size
1.5 gb
emmc flash
8 gb (* available storage will be less than the total memory due to storage of operating system and software pre-installed on the device.)
software configuration :
os google
google play store
yes
screen mirroring
chromecast
youtube
yes
netflix
yes
wifi built in
2.4g+5g 2t2r
hdmi (cec,arc)
yes
panel specification:
backlight unit
dled
aspect ratio
16:09
panel size
813 mm
display resolution
1366 x 768
brightness
190 ± 10 cd/m2 (for ips display), 170 ± 10 cd/m2 (for va display)
contrast
1100:1 (for ips display), 3000:1 (for va display)
color
black
frame rate
60 hz
power supply and consumption:
power supply
ac 110v-240v 50/60hz
power consumption (tv on)
60 w
power consumption (stb)
< 0.5 w
sound:
audio power output
2 x 8 watt
sound mode
user, standard, vivid, sports, movie, music, news
sound control
2 ch speaker system
terminals:
rj45 (lan port)
1
composite video input (rca)
1
hdmi
2 (side 2.0*2)
spdif output (optical/coaxial)
1(opitical)
rf in
1
usb 2.0
2
device media format:
audio
mp3; wav;acc;ac3
jpeg/bmp/png
video
mp4; ts/trp; mpg; mov; dat; flv;3gpp
text
txt
subtitle
srt; .sub; .smi
tv system:
video system
pal/ secam/ ntsc
sound system
bg/ d/ k/ i
receiving range
48.25mhz - 863.25 mhz
receive channel
99
dimensions & weight :
tv with stand (l × w × h) 718 mm x 193 mm x 473 mm
tv without stand (mm) (l×w×h) 718 mm x 87 mm x 427 mm
tv shipping dimension (mm) (l×w×h) 775 mm x 124 mm x 485 mm
tv weight with stand 3.66 kg
tv without stand weight 3.62 kg
tv shipping weight 5.48 kg
loading :
shipping qty (40hc)
1370 pcs (approx.)
shipping qty (40gp)
1096 pcs (approx.)
shipping qty (20gp)
528 pcs (approx.)
warranty information:
- tv replacement guarantee through digital registration: 3 months (condition applicable)
- led panel: 3 years
- spare parts: 2 years
- free service: 5 years
