Specification
key features
certification: 80 plus gold
fan size: 120mm silent fan
lighting effect: n/a
others: 120mm silent fan
active pfc
power good signal: 100-150ms
protection: ocp, ovp, uvp, scp, opp, otp, sip, nlo
regulatory: tuv / cb / ce / kc / ukca / rcm / ctuvus
/ fcc / ices / bsmi / 3c / bis
atx 3.1 & pcie 5.1 compatible
high-quality braided cable
phasewave design
input
voltage: 100v-240v
frequency range: 50hz-60hz
current: 10a max
output
modular type: full modular
total power: 750w
connector
main power: 1 x 24(20+4)pin mb
cpu: 2 x 8(4+4)pin cpu
1 x 16(12+4)pin pcie 5.1 12v-2x6
pci-e: 4 x 8(6+2) pin pci-e
sata: 8 x sata
molex: 4 x molex
